CT8.4LCRS
BW138
€4,499.00
Tax included
In-wall speakers
|
Technical features |
Nautilus™ tube-loaded tweeter |
|---|---|
|
Description |
3-way closed-box system |
| Frequency range |
-6dB at 39Hz and 40kHz |
| Frequency response |
49Hz – 24kHz ±3dB on reference axis |
| Sensitivity | 88dB spl (2.83V, 1m) |
| Nominal impedance | 8Ω (minimum 3Ω) |
| Recommended amplifier power |
50W – 200W into 8Ω on unclipped programme |
| Max. recommended | cable impedance 0.1Ω |
| Dispersion | Within 2dB of reference response Horizontal: over 60º arc Vertical: over 10º arc |
| Harmonic distortion | 2nd and 3rd harmonics (90dB, 1m) <1% 80Hz – 20kHz <0.5% 200Hz – 20kHz |
| Crossover Frequencies | 380Hz, 4kHz |
| Dimensions |
Height: 630mm (24.8 in) |
|
Net weight |
21.0kg (46.3 lb) |
|
Finishes |
Cabinet Black painted |
- Series:
- Custom Theathre 800 Series
