PL-563
SF-PC-582
€1,000.00
€1,000.00 gb./шт.
Tax included
Acoustics built into the suspended ceiling
| Loudspeaker system | 2 way in-ceiling loudspeaker system. Open design. |
| Tweeter DADTM driver | 29 mm / 1,1'' |
| Midwoofer | 200 mm / 7,8'' |
| Woofer | - |
| Crossover frequency Paracross TopologyTM | 2.500 Hz |
| Frequency response | 40 Hz -25.000 Hz |
| Sensitivity (2.83v/1m) | 87dB SPL |
| Nominal impedance | 4 |
| Suggested amplifier power output | 40W - 200W |
| Long-term max input voltage (IEC-268-5) | 20V rms |
| Frame outer | 283 mm / 11.1'' |
| Cut out | 257 mm / 10.1'' |
| Depth behind surface | 139 mm / 5.5'' |
| Protrusion | 13 mm / 0.51'' |
| Included in the box | Bezel-Free square and round magnetic grilles |
- Series:
- Palladio Level 5
- Sensitivity:
- 92 dB/2,83 V/ 1m
- Frequency:
- 50 - 25,000 Hz
- Power:
- 250 W
- Number of Ways:
- 2
- NOMINAL IMPEDANCE:
- 4 Om
- Dimensions:
- Frame outer: 471 x 216 mm - 18.5 x 8.5’’
Cut out: 448 x 192 mm - 17.6 x 7.6’’
Depth behind surface: 100 mm / 4’’
Protrusion: 13 mm / 0.51’ - Weight:
- 6.3 Kg
- Type:
- pasīvs
