PL-664
SF-PL-664
€2,000.00
€2,000.00 gb./шт.
Tax included
Wall acoustics
| Loudspeaker system | 3 way left/right/center in-wall. Sealed design. (Optionally openable) |
| Tweeter DADTM driver | 29 mm / 1,1'' |
| Midwoofer | Midrange: 80 mm / 3,1'' |
| Woofer | 2 x 165 mm 2 x 6,5'' |
| Crossover frequency Paracross TopologyTM | 250 Hz -1.650 Hz |
| Frequency response | 38 Hz -25.000 Hz |
| Sensitivity (2.83v/1m) | 90dB SPL |
| Nominal impedance | 4 |
| Suggested amplifier power output | 40W - 200W |
| Long-term max input voltage (IEC-268-5) | 22V rms |
| Frame outer | 655 x 270 mm 25.7 x 10.6'' |
| Cut out | 247 x 632 mm 9.7 x 24.8'' |
| Depth behind surface | 113 mm / 4.5'' |
| Protrusion | 13 mm / 0.51'' |
| Included in the box | Bezel-Free square magnetic grilles |
| Additional fittings | Natural walnut wood front mask |
| String grilles |
- Series:
- Palladio Level 6
- Sensitivity:
- 90 dB/2,83 V/ 1m
- Frequency:
- 56 - 25,000Hz(-6dB)
- Power:
- 200 W
- Number of Ways:
- 3
- NOMINAL IMPEDANCE:
- 4 Om
- Dimensions:
- Frame outer: 751 x 288 mm / 29.5 x 11.3’’
Cut out: 724 x 265 mm / 28.5 x 10.4’’
Depth behind surface: 100 mm / 4’’
Protrusion: 15 mm / 0.59’’ - Weight:
- 10,3 kg
- Type:
- pasīvs
