805D3 Prestige Edition

Technical features
Diamond tweeter
Continuum™ cone bass mid
Anti-resonance plug
Flowport™
Optimised Matrix
Solid body tweeter
Tweeter-on-Top

Description
2-way vented-box system

Drive units
1x ø25mm (1 in) Diamond dome high-frequency
1x ø165mm (6.5 in) Continuum™ cone bass midrange

Frequency range
34Hz to 35kHz

Frequency response (+/-3dB from reference axis)
42Hz to 28kHz

Sensitivity (1m on axis at 2.83Vrms)
88dB

Harmonic distortion
2nd and 3rd harmonics (90dB, 1m on axis)
<1 % 70Hz - 20kHz
<0.6% 120Hz - 20kHz

Nominal impedance (min)
8Ω (minimum 4.6Ω)

Recommended amplifier power
50W - 120W into 8Ω on unclipped programme

Max. recommended cable impedance
0.1Ω

Dimensions
Height: 424mm
Width: 238mm
Depth: 345mm

Net weight
12.6kg (28lb)

Cabinet finishes
Prestige

Grille finishes
Black
Grey
