CP-WT150
MA-092
€250.00
Tax included
Wall-mounted acoustics
Frequency Response
75 Hz – 25 kHz
Nominal Impedance
6 ohms
Sensitivity (1W@1M)
85 dB
Maximum SPL
102.8 dBA
Power Handling (RMS)
50 W
Recommended Amplifier Requirements
20 – 50 W
Crossover Frequency
2.8 kHz @ 12 dB / Octave
Drive Unit Complement
2-Way
5" MMP II cone bass driver
1" C-CAM Gold Dome tweeter
Adjustment Controls
HF Level Switch (+3 dB / 0 dB / -3 dB)
Overall Dimensions (H x W x D)
360.5 x 242 mm (143/16 x 91/2")
Overall Depth (Including Grille)
102 mm (4")
Cut-Out Dimensions
326 x 207 mm (1213/16 x 81/8")
Mounting Depth
96 mm (33/4")
Fixing Type
6 position Tri-Grip dog leg fixings
Construction Material
Mineral Filled ABS Plastic (RoHS2 Compliant)
Connection
Gold plated 'push' type terminals
Weight
2.65 kg (5 lb 14 oz)
Pre-Construction Bracket
Sold As
Single Unit
- Series:
- Build-in - Controlled Performance Series
