A14
rotel003
€1,279.00
Tax included
Integrated amplifier
CONTINUOUS POWER OUTPUT
80W/Ch (All channels driven, 8Ω)
TOTAL HARMONIC DISTORTION (THD)
(20Hz–20kHz) <0.03%
FREQUENCY RESPONSE
Line Level Inputs: 10Hz - 100kHz ±0.5dB
Digital Inputs: 10Hz - 80kHz ±3dB
Phono Input: 20Hz - 15kHz ±0.5dB
S/N RATIO (IHF "A" Weighted)
Line Level Inputs: 100dB
Digital Inputs: 103dB
Phono Input: 90dB
DIMENSIONS (W × H × D)
430 × 93 × 345mm
17" × 3.6" × 13.5"
17" × 3.6" × 13.5"
FRONT PANEL HEIGHT
80mm (3.15")
POWER REQUIREMENTS
230V, 50Hz
POWER CONSUMPTION
280W
STANDBY POWER CONSUMPTION
<0.5W
NET WEIGHT
8.2kg (18lbs.)
BTU RATING (4Ω, 1/8th power)
632 BTU/h
No reviews
