Galapastiprinātāji
MC8207
MCI-MC8207
11 090,00 €
11 090,00 € gb. / шт. / pc.
AR PVN
- 200 Watts x 7 Channels
- 7 balanced XLR inputs
ELECTRONIC SPECIFICATIONSPOWER OUTPUT PER CHANNEL200W @ 4 or 8 Ohms NUMBER OF CHANNELS7 (can also be used as a 2-zone amplifier with 5 channels in zone A and 2 channels in zone B) TOTAL HARMONIC DISTORTION0.005% S/N BELOW RATED OUTPUT112dB DYNAMIC HEADROOM1.7dB DAMPING FACTOR140 RATED POWER BAND20Hz to 20kHz FREQUENCY RESPONSE +0,-0.25DB20Hz to 20kHz FREQUENCY RESPONSE -3DB10Hz to 100kHz CONTROLREMOTE POWER CONTROLYes, 7 or 5 + 2 Channel MULTI CHANNEL DB25 CABLEN/A GENERAL SPECIFICATIONSCIRCUIT CONFIGURATIONPush-Pull Complementary CIRCUIT DESIGNTransistor MONO BRIDGENo MONO PARALLELNo AUTOFORMERNo METERSYes, new style LED METER LIGHT SWITCHNo BALANCED INPUTYes FRONT PANELGlass ILLUMINATIONLED Fiber Optic CHASSIS STYLEInverted GOLD PLATED BINDING POSTSYes WEIGHTS & DIMENSIONSDIMENSIONS (W X H X D)17-1/2" (44.5cm) x 9-7/16" (23.9cm) (including feet) x 21" (53.3cm) (including front panel and cables) WEIGHT83 lbs (37.6 kg) SHIPPING WEIGHT116 lbs (52.6 kg) |
- Izmēri:
- 44.5cm x 23.9cm (including feet) x 53.3cm (including front panel and cables)
- Svars:
- 37.6 kg
- Pastiprinātāja tips:
- Izbeigšana
- Būves shēma:
- Tranzistors
- Kanālu skaitlis:
- 7
- Pretestība:
- 4 or 8 Ohms
- Jauda katram kanālam (Watt):
- 200 W
- Kopējais harmoniskais kropļojums:
- 0.005%
- Signāla-trokšņa attiecība:
- 112dB
