McIntosh PS1K

• (2) 13-дюймовых вуфера
• (2) Усилители мощностью 500 Вт
• Номинальная мощность до 1000 Вт
• Регулируемые фильтры нижних и верхних частот, параметрические фильтры эквалайзера, регулировка уровня и регулировка фазы
• Особо толстая перегородка корпуса обеспечивает максимальную жесткость и низкий уровень вибрации

Electronic Specifications

• Impedance Nominal

  8 Ohms

• Power Output

  1KW (Two 500W, one per woofer)
  Maximum Output > 113 dB

• Frequency Response

  20Hz - 500Hz with LFE
  20Hz - 100Hz without LFE

• Filter Frequencies

  High Pass: 40Hz - 100Hz
  Low Pass: 40Hz - 100Hz
  Phase: Continuously Variable
  Parametric: Two band 30Hz - 100Hz, variable bandwidth and level +/- 8dB

• Input Sensitivity

  1V Balanced
  500mV Unbalanced (0.5V)

• Total Harmonic Distortion

  Amplifier: 0.05%
  Preamplifier (rear panel outputs): 0.005%

• Voltage Gain

  Amplifier: 31dB
  Preamplifier: 10dB

• Signal To Noise Ratio

  Amplifier: 115dB A Weighted
  Preamplifier: 100dB A Weighted

• Input Impedance

  20K Ohms Balanced
  10K Ohms Unbalanced

• Maximum Input Signal

  9V Balanced
  4.5V Unbalanced

Driver Specifications

• Number of Woofers

  2

• Woofer Size

  13"

• Woofer Type

  Carbon Fiber with extra long excursion and Low Distortion High Performance (LD/HP®) Magnetic Circuit Design

Connectivity

• Balanced Input

  1 Pair Stereo
  1 Subwoofer (mono)

• Unbalanced Input

  1 Subwoofer (mono)

• Balanced Output

  1 Pair Stereo
  1 Subwoofer (mono)

• Unbalanced Output

  1 Subwoofer (mono)

General Specifications

• Enclosure Finish

  Highly polished Piano Black

• Metal Finish

  Anodized aluminum base
  High Durable powder coated plate surfaces

Weights & Dimensions

• Unit Dimensions (W x H x D)

  19-1/4” (48.9cm) x 50-1/16” (128.7cm) x 22-1/2” (57.2cm)
  Base footprint: 25-5/16" (64.3cm) x 28-7/16" (21.43cm)

• Unit Weight

  370 pounds (167.8 kg)

• Shipping Weight

  638 pounds (310 kg)
