MM7055 (black)

FEATURES MM7055

• Channels 5
• Current Feedback Topology o
• Phono EQ: Standard/Current Feedback/Constant
• Current Feedback
• - / - / -
• HDAM version -
• Power Transformer: Toroidal/El -/ o
• High Grade Audio Components o
• Customised Components o
• Symmetric PCB layout -
• Aluminium extrusion heatsink o
• Copper plated chassis -
• Tri-Tone Control (Bass/Mid/Treble) -
• Balance/Bass/Treble/Loudness - / - / - / -

OTHERS

• Linear Drive Power Supply o
• BTL possibility -
• Bi-Amp and Multichannel option -
• Shottkey diodes -
• Input Buffer Amp (All inputs/CD only) o / -
• Seperate solid heatsinks -
• System block shielding: copper/metal/none - / - / -
• Double layer bottom plate -
• Source Direct -
• Power Amp Direct o
• Standby mode o

INPUTS/OUTPUTS

• Phono Input: MM/MC - / -
• Balanced In/Out 5 / -
• Pre-Out/Main In - / 5
• Power Amp Direct In o
• Gold Plated Chinch -
• Speaker A/B -
• Speaker terminal: Screw/Marantz/WBT o / - / -
• Number of terminals 5
• Marantz remote bus o
• Remote power control (Trigger In/Out) o
• Flasher In/IR receiver In o / -
• Headphone Out -

SPECIFICATIONS

• Power Output (8/6 Ohm RMS) 140/170 Watts
• Power Output (8/6 Ohm DIN) -
• Power Output (8/6 Ohm IHF) -
• Bridged Power Output (8 Ohm RMS) -
• Frequency Response 8Hz-100kHz
• Total Harmonic Distortion 0.03%
• Damping Factor 100dB
• Input Sensitivity: MM -
• Input Sensitivity: MC -
• Signal to Noise Ratio: MM/MC - / -
• Input Sensitivity: High level 1.2V/22kohm
• Input Sensitivity: Balanced High level 2.4V/30kohm
• Signal to Noise Ratio: High level 105dB

GENERAL

• Available colors: Gold/Silver/Black/Silver-Gold -/-/o/-
• Metal Front Panel o
• Power Consumption in W 440
• Standby Consumption in W 0.4
• Auto Power off o
• Detachable Power Cable o
• Remote Control -
• System Remote Function -
• Maximum Dimensions (W x D x H) in mm 440x384x184.5
• Weight in kg 15.2
