McIntosh MPC500

ELECTRONIC SPECIFICATIONS

• Load Regulation

  N/A

• Output Voltage


  With Type F (a.k.a. CEE 7/3 or “Schuko”) receptacles:
  240 Volts AC Nominal

• Power Requirement


  With Type F (a.k.a. CEE 7/3 or “Schuko”) receptacles:
  240 Volts, 50Hz
  6.0 Amps (max)
  1440 Watts (max)

GENERAL SPECIFICATIONS

• AC Power Line Protection

  3 thermally protected metal-oxide varistors (TPMOVs)

• Surge Suppression Type

  AC Power Line: 3 thermally protected metal-oxide varistors (TPMOVs)
  Secondary Surges: GDTs, PTC thermistors, TVS components

• Number of Receptacles


  With Type F (a.k.a. CEE 7/3 or “Schuko”) receptacles:
  4

• Number of Always ON Receptacles


  With Type F (a.k.a. CEE 7/3 or “Schuko”) receptacles:
  1

• Number of Programmable Receptacles


  With Type F (a.k.a. CEE 7/3 or “Schuko”) receptacles:
  3

• Meters

  0

• Meter Light Switch

  N/A

WEIGHTS & DIMENSIONS

• Dimensions (W x H x D)

  17-1/2” (44.45cm) x 6” (15.2cm) x 19” (48.26cm)

• Weight

  18.5 lbs (8.39 kg)

• Shipping Weight

  34 lbs (15.42 kg)
